Physical Characteristics
Functional Characteristics
RLD10-MAN P. 4
Size: Height by Width by Depth
(with probe wrapped around boot)
Probe length: fully extended
Weight (battery installed)
8” x 4” x 1 1/2”
18 1/2” (47cm)
14.1 Oz (400g)
Power requirements
Average battery life (Continuos use)
Leak detection sensitivity
Sensor
Duty cycle
Typical response time
Warm up period
Sensor output (voltage/current)
Visual level indicators
One 9 volt alkaline battery
Approximately 8 hours
.4 Oz/year (11 grams/year) R134A
using LS20 leak standard
Corona discharge
Continuos
Less than 1 second
(allows for 1”/sec seek rate)
10 second average
A. No -load high voltage: 2500V ±10%
B. Current: 24 mA
C. Loaded high voltage: 2400V ±50V
(loaded with 100.0 M Ohms
Four tic-rate scaled LED indicators
changing from green to yellow to light
red to red (indicating relative,
not specific quantities)
