UNI-T UPO3000E Series User Manual

I2C Decode (Optional)
Trigger Condition
Address byte Width
Address Range
Byte Size
Data Qualifier
Start, restart, stop, lost acknowledgment , address, data, address/data
7 bits, 10 bits
0 to 119, 0 to 1023
1bit to 5bits
Equal to, greater than, less than
SPI Decode (Optional)
Trigger Condition
Idle Time
Data bit size
Data Setting
Clock Edge
Chip select, timeout
80ns~1s
4 bits to 32 bits
H, L, X
Rising edge, falling edge
USB Decode (Optional)
Signal Speed
Trigger Condition
Low speed, full speed
Synchronization, reset, pause, restore, packet tail, token packet, data packet, handshake packet, SOF, error.
CAN Decode (Optional)
Signal Type
Trigger Condition
Signal Rate
Rx/Tx, CAN_H, CAN_L, Difference
Frame start, frame type, ID, data, ACK missing, bit stuffing error, ID and data, frame end
10kbps, 20kbps, 33.3kbps, 50kbps, 62.5kbps, 83.3kbps, 100kbps, 125kbps, 1Mbps, user-defined
62
