Unison Research Unico 90 Instruction Manual

14
L’Unico90 has two LEDs which provide the user with important
information about the operating condition of the amplifier.
LED INPUT AND LED VOLUME ON:
indicates normal operation
LED INPUT AND LED VOLUME blinking (fast):
indicates automatic start-up phase (approx 40 seconds)
LED INPUT AND LED VOLUME blinking (slow):
indicates intervention of the thermal protection device, power stage
is switched off.
When the internal temperature has returned to normal the amplifier
will switch on automatically and repeat the initial start-up phase.
It is advisable to switch off if the amplifier if the thermal protection
device intervenes. This will speed up return to normal operation
LED INPUT ON e LED VOLUME blinking:
indicates that the amplifier is receiving a signal from the IR remote
control (volume changing).
If there is a temporary loss of mains electricity (even of very short
duration) the amplifier will restart in automatic start-up mode.
REMOTE CONTROL
Unison Research

amplifiers are supplied complete with infrared
remote control.
Your remote control handset is fitted with a battery type CR2032 -
3V (lithium battery).
IMPORTANT! The use of the remote control with Unico 90
allows only volume control by acting on Vol- e Vol+ buttons.
Line Outputs:

Unison Research Unico 90 Specifications

Output Power

output power at 8Ω	100+100 W RMS
output power at 4Ω	180+180 W RMS

Frequency Response

frequency response at -1dB	12Hz to 45kHz
frequency response at -3dB	6Hz to 80kHz

Input Specifications

input impedance	21kΩ //300pF
input sensitivity	860mV RMS
input	6 line (3 unbalanced, 2 balanced, 1 'bypass' unbalanced)

Output Specifications

line outputs	1 tape, 1 sub (volume controlled)
output connectors	4 + 4 bi-wiring
output resistance	<0.4 ohm, resistive on all audio frequencies

Power and Consumption

power consumption	550 W (at max power on 8 ohm)
global feedback factor	0 dB
THD at 1kHz, 1 W	< 0.15%

Weight and Dimensions

dimensions	43.5cm x 18 cm x 44 cm
net weight	20 kg
