Unitech MS912 User Manual

10
Unitech electronics co., ltd.
5F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
 Tel: + 886 2 89121122  Fax: +886 2 89121810  website: www.ute.com
Scan the Default Wireless ID barcode. .B022$
STEP 2
Scan the Set Wireless ID barcode. .B023$
STEP 3
Scan 7 alphanumeric characters from Full ASCII Chart of Appendix A.
STEP 4
Scan the Set Wireless ID barcode. .B023$
STEP 5
Scan a desired BT mode barcode (SPP or HID) to connect.
*Note:
1. If you have connected the scanner with the host BEFORE customizing your Bluetooth device name, please
remove the device and create a new connection to make sure device name is refreshed. For PC, it is
recommended to restart the Bluetooth adaptor in order to refresh device name.
2. At Step 3, the scanner will beep three times as an alert that more than 7 characters are entered.
Power Management
When not being used, the scanner will enter idle mode to conserve battery power. Scan the
appropriate barcode below to set the time it takes the scanner to enter idle mode after any
scanning activity.
Scanner LED & Beeper Indication
Scanner LED & Beeper Indication
1 Minute
3 Minute (Default)
5 Minute
10 Minute
Idle Mode Disable

Unitech MS912 Specifications

General

Type	Handheld bar code reader
Sensor type	CCD / CMOS
Scanner type	1D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Product color	Black, White
Housing material	ABS synthetics
Battery voltage	3.7 V
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %
Cables included	USB

Weight and Dimensions

Depth	72 mm
Width	30 mm
Height	20 mm
Weight	30.2 g
