1. Specifications
Input/Output
Number of Point 1 point (TC, RTD or Linear)
Type
TC: K,J,R,S,B,E,T
RTD : Pt-100
Linear : 4~20mA / 2~10V DC (500 Resistance connected Across)Ω
Note :
Refer to Table A.
For input Type symbols and Ranges.
Sampling cycle 250 ms
Indication
Accuracy
± 0.2% FS ± 1digit (for details Table1-1)
Cold junction
accuracy
±1.0ºC (under standard conditions)
Input bias (offset) LSPL ~ USPL
Digital Filter 0 - 200 sec (0: filter off)
Analog
Input 1
Decimal Point 0000, 000.0, 00.00, 0.000
0~20mA / 0~10V DC (500 Resistance connected Across)Ω
Output Alarm Output Relay Contact Output : 250V AC, 3A (Resistive Load)
Control Output Relay Contact Output : 250V AC, 3A (Resistive Load)
Voltage Pulse 0/12V DC. (Load Resistance 600 or More)Ω
Current Output 4 to 20mA DC. (Load Resistance 500 or Less)Ω
Trigger Output 100A or LessCurrent Output
(For TRIAC Driving)
2. Mounting
Mounting Cautions :
(1) Use this instrument within the following ambient temperature and ambient humidity.
Allowable ambient temperature: 0 to 50°C
Allowable ambient humidity: 45 to 85% RH
(2) Avoid the following when selecting the mounting location.
Rapid changes in ambient temperature which may cause condensations.
Corrosive or inflammable gases.
Direct vibration or shock to the mainframe.
Water, oil, chemicals, vapour or steam splashes.
Excessive induction noise, static electricity, magnetic fields or noise.
Direct air flow from an air conditioner.
Exposure to direct sunlight.
Excessive heat accumulation.
z
z
z
z
z
z
z
z
z
z
