Apollo x8p Hardware Manual Rear Panel 24
Rear Panel
Apollo x8p rear panel (digital portion)
(28) Power Input
The included external power supply connects to this 4-pin locking XLR jack. Apollo x8p
requires 12 volts DC power and draws a maximum of 72 watts (30 watts typical).
To eliminate risk of circuit damage, connect only the factory-supplied power supply. Use
the Power switch on the front panel to power the unit on and off.
Important: Do not disconnect the power supply while Apollo x8p is in use,
and confirm the Power switch is in the “off” position before connecting or
disconnecting the power supply.
MONITOR
R
L
POWER IN
+12VDC 9.0A
WORD CLOCK
75 Ω
TERM
LINE OUT 1-8 (ALT SURROUND)
LINE IN 1-8
12345678
MIC/LINE INPUT
ADAT S/MUX
UNIVERSAL AUDIO, INC.
34
28 31
36
30
35
29
32
33
INPUT
MONITOR
HI-Z 2
HI-Z 1
PAD
INPUT
+48V
Ø LINK
METER
ALT
FCN
POWER
OFF
HP 1 HP 2
4 5 72
3 11
13
17
16 18 19 20
22
23 24
26
27 252112
14
1
10
6
8
9 15
1
2 3 4
5
6 7 8
