Unox CHEFTOP MIND.Maps XAVC-10FS-GPR User Manual

19
USA
Oven model**
Trays
type
N° Trays
Dimensions
[inches - mm]
Weight*
[lbs - Kg]
XAVC-0511-GPR
GN 1/1
5 29” 17/32 x 30” 7/16 x 33” 3/16 - 750x773x843 202 lbs - 92 kg
XAVC-1011-GPR 10 29” 17/32 x 30” 7/16 x 39” 3/4 - 750x773x1010 258 lbs - 117 kg
XAVC-0621-GPR
GN 2/1
6
33” 27/32 x 44” 3/32 x 33” 3/16 - 860x1120x843 408 lbs - 185 kg
XAVC-1021-GPR 10 33” 27/32 x 44” 3/32 x 45” 25/32 - 860x1120x 1163 434 lbs - 197 kg
XAVC-2021-GPR 20 33” 27/32 x 47” 33/64 x 73” 15/32 - 860x1207x1866 529 lbs - 240 kg
XAVC-06FS-GPR
18”x26
6 33” 27/32 x 37” 11/16 x 33” 3/16 - 860x957x843 258 lbs - 117 kg
XAVC-10FS-GPR 10 33” 27/32 x 37” 11/16 x 45” 25/32 - 860x957x1163 335 lbs - 152 kg
XAVC-16FS-GPR 16 34” 23/32 x 41” 1/16 x 73” 15/32 - 882x1043x1866 485 lbs - 220 kg
Oven model**
Amperage
Draw for
oven
Circuit
Breaker
Amperage
Electrical and Gas ratings
Power
[kW]
GAS
burner
power
[kW]
kW/tray kW/m
2
Electrical
connection
XAVC-0511-GPR 5 15 0,6 15 3,00 17,42 120V/1P+N/60Hz
XAVC-1011-GPR 8,3 15 1 22 2,20 12,77 120V/1P+N/60Hz
XAVC-0621-GPR 11,7 15 1 24 4,00 11,61 120V/1P+N/60Hz
XAVC-1021-GPR 8,3 15 1,4 33 3,30 9,58 120V/1P+N/60Hz
XAVC-2021-GPR 20 25 2,4 80 4,00 11,61 120V/1P+N/60Hz
XAVC-06FS-GPR 8,3 15 1 24 4,00 13,56 120V/1P+N/60Hz
XAVC-10FS-GPR 11,7 15 1,4 33 3,30 11,19 120V/1P+N/60Hz
XAVC-16FS-GPR 20 25 2,4 80 5,00 16,95 120V/1P+N/60Hz
* The values refer to the appliance when empty.
** Oven listed as example have final letter R that means the right to left door opening. All the ovens
with final letter L have the left to right door opening.
TECHNICAL DATA
