Uponor Fluvia T Push-12 CH-G User Manual

212.5
100
331.5
G ¾*
60
40
15
G ¾*
*eurocone
Q ≤ 3 kW
kvs = 0.7 m³/h
P
max
= 10 bar
θ
sec
= 20-50 °C
θ
prim
= < 90 °C
SI0000267
G ¾*
Q = 500 W
170
161
50
80
80
∆P < 20 kPa (0.2 bar)
∆P
max
= 100 kPa (1 bar)
T
Renovis (wall) 1 loop = 20 m² 2.0 kW
UFH d = 9,9 mm T = 100 mm 2 loops à 60 m = 2x6 m² 0.96 kW
UFH d = 12 mm T = 150 mm 2 loops à 46 m = 2x7 m² 1.4 kW
UFH d = 14 mm T = 150 mm 2 loops à 60 m = 2x9 m² 1.8 kW
UFH d = 16 mm T = 150 mm 2 loops à 75 m = 2x11 m² 2.2 kW
UFH d = 17 mm T = 150 mm 2 loops à 90 m = 2x14 m² 2.84 kW
UFH d = 20 mm T = 150 mm 2 loops à 105 m = 2x16 m² 3.2 kW
180°
90°
22
40
Ø 8 mm
SI0000268
1
Uponor Fluvia T pumpgroup Push-12 CH-G
|
Installation and operation manual
|
31

Uponor Fluvia T Push-12 CH-G Specifications

General

Brand	Uponor
Model	Fluvia T Push-12 CH-G
Category	Heat Pump
Language	English
