urmet domus BiBus II 1072/9 User Manual

17
DS1072-034
Letter “D” identities the lock activation time:
Pulse: D00↵
Door lock xy seconds: Dxy↵
Code button association
This is the step in which user codes to be programmed are associated to each button connected to the
digitiser. The call code sequence is:
CxyzwPnm↵
where xyzw is the user code and nm is the calling station button number.
The user code xyzw can have the following values:
0001-9999 for numeric code formats
x000-x999 for alphabetic prex code formats (x from A to J)
000x-999x for alphabetic sufx code formats (x from A to J)
0000 for direct calls to switchboard in day mode
LLLL for “staircase lights” function
The button number nm depends on the position of the terminal to which it is connected according to the
following table:
1-18: door unit with digitiser 1072/9
19-34: 1st expansion module
35-50: 2nd expansion module
51-66: 3rd expansion module
67-82: 4th expansion module
Once a code is programmed, press button ↵ to automatically program call code xyzw+1 on button nm+1.
For example, the calling sequence C1000P01↵↵↵ will program code 1000 on button 01, code 1002 button
02 and code 1002 on button 03.
1st edition system: this programming is not required.
Programming door phones in 2nd edition systems using the programming adapter
The door phone programming sequence consists of two steps:
Door phone booking (to be made on a calling station).
Door phone programming (to be made in the apartments).
A: Door phone booking
Insert adapter 1072/60 in the specic minidin connector.
Press the user buttons to be associated with the door phones once. The booking sequence according to which
the buttons are pressed must be the same as the order in which the operator will go to the apartments. DO NOT
press the switchboard call button or the “staircase lights” function.
A beep will be heard after 30 seconds from last pressing a user button (end of booking).
Leave the adapter 1072/60 in the digitiser and go to the apartments to program the door phones.
B: Door phone programming
Go to the rst booked user, hold the button pressed and lift the door phone handset. Two conrmation
beeps will be heard and the LED will ash to indicate that it has been programmed.
Go to the other booked users and repeat the operations.
Refer to the attached sheet to remember the code/button association sequence.
SEQUENZA DI ASSOCIAZIONE
ASSOCIATION SEQUENCE
N° DELLA POSTAZIONE (ID):
CALL MODULE NUMBER (ID):
SEQ. NOMINATIVO PULSANTE / CODICE PIANO VARIE
USER NAME PUSHBUTTON / CODE FLOOR VARIOUS
1
2
3
Associating 2/3 door phones in parallel in 2nd edition systems using the programming adapter
To install two or three door phones in one apartment and make them both ring when a call is received, press
the button related to the user twice or three times with the door phones in parallel when booking the door
•
•
•
•
•
•
•
•
•
•
•
•
•
A.
B.
1.
2.
3.
4.
1.
2.
