V2 CALYPSO Series User Manual

ENGLISH
- 9 -
EU DECLARATION OF CONFORMITY
AND DECLARATION OF
INCORPORATION OF PARTLY
COMPLETED MACHINE
Declaration in accordance with Directives: 2014/35/UE (LVD);
2014/30/UE (EMC); 2006/42/CE (MD) ANNEX II, PART B
The manufacturer (*) V2 S.p.A., headquarters in Corso Principi di
Piemonte 65, 12035, Racconigi (CN), Italy
Under its sole responsibility hereby declares that:
the partly completed machinery model(s):
CALYPSO400-230V (*), CALYPSO500-230V (*)
CALYPSO600-230V (*)
CALYPSO400-120V (*), CALYPSO500-120V (*)
CALYPSO600-120V (*)
CALYPSO400-24V (*), CALYPSO500-24V (*)
CALYPSO600-24V (*)
Description: electromechanical actuator for gates
• is intended to be installed on gates, to create a machine
according to the provisions of the Directive 2006/42/EC.
The machinery must not be put into service until the final
machinery into which it has to be incorporated has been
declared in conformity with the provisions of the Directive
2006/42/EC and 89/106/CE.
• is compliant with the applicable essential safety requirements
of the following Directives:
Machinery Directive 2006/42/EC (annex I, chapter 1)
Low Voltage Directive 2014/35/EU
Electromagnetic Compatibility Directive 2014/30/EU
Directive ROHS2 2011/65/CE
The relevant technical documentation is available at the national
authorities’ request after justifiable request to:
V2 S.p.A., Corso Principi di Piemonte 65, 12035, Racconigi (CN),
Italia
The person empowered to draw up the declaration and to provide
the technical documentation:
Antonio Livio Costamagna
Legal representative of V2 S.p.A.
Racconigi, il 01/06/2015
(*) made in extra EU Countries on behalf of V2 S.p.A.
TECHNICAL DATA
CALYPSO
400-230V
CALYPSO
500-230V
CALYPSO
600-230V
CALYPSO
400-120V
CALYPSO
500-120V
CALYPSO
600-120V
CALYPSO
400-24V
CALYPSO
500-24V
CALYPSO
600-24V
Max. leaf lenght
m 2,5 3 4 2,5 3 4 2,5 3 4
Max. leaf weight
Kg 400 500 500 400 500 500 300 400 400
Power supply
Vac - Hz 230 - 50 230 - 50 230 - 50 120 - 60 120 - 60 120 - 60 24 Vdc 24 Vdc 24 Vdc
Idling current
A 0,8 0,8 0,8 2 2 2 2 2 2
Full load current
A 1,2 1,2 1,2 2,8 2,8 2,8 10 10 10
Electric power
W 200 200 200 300 300 300 - - -
Opening time of the
leaf 0÷90°
s 22 25 30 22 25 30 22 27 35
Capacitor
µF 8 8 8 25 25 25 - - 8
Max travel
mm 400 500 600 400 500 600 400 500 600
Operating speed
m/s 0,016 0,016 0,016 0,018 0,018 0,018 - - -
Maximum thrust
N 2300 2300 2300 2300 2300 2300 2000 2000 2000
Working temperature
°C -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50 -30 ÷ +50
Protection
IP 44 44 44 44 44 44 44 44 44
Working cycle
% 30 30 30 30 30 30 90 90 90
Motor weight
Kg 6,5 6,8 7,1 6,5 6,8 7,1 6,3 6,6 7,1
