Valtra T2 Versu Series User Manual

2.3.5 Auxiliary hydraulics
The following instruments and controls are used to control the auxiliary hydraulics.
6
1
5
7
8
9
10
2
4
3
11
12
GUID-7166BEEC-2E31-486D-988D-ED1530080B1E
1. Change-over switch for front linkage/front loader (extra equipment)
2. Switch for rear on/off valve 1
3. Switch for rear on/off valve 2 (extra equipment)
4. Release switch for equipment locking (extra equipment)
5. Switch for Softdrive (extra equipment)
6. Auxiliary hydraulics on/off push button
7. Selector for the predefined factory/user settings
8. Joystick functions selector
9. Joystick push buttons
10. Joystick
11. Control levers for the rear valves 3, 4 and 5 (extra equipment)
12. Control lever for the third front valve (extra equipment)
2. Instruments and controls
- 31 -
