Vector JUMP-START SYSTEM User Manual

10
5. EMERGENCY WORKLIGHT
The Worklight is controlled by an On/Off switch. Make sure the lamp is turned OFF
when the unit is being recharged or stored.
6. REPLACEMENT PARTS
For replacement parts (bulbs, batteries, fuses, etc.), contact Vector Customer
Service: (954) 584-4446 or toll-free (866) 584-5504.
6.1 Batter
y replacement
It is recommended that the unit be returned to Vector Customer Service for
battery replacement: Contact (954) 584-4446 or toll-free (866) 584-5504.
WARNING
• Do not dispose of the battery in fire as this may result in an explosion
• Before disposing of the battery, protect exposed terminals with heavy-duty
electrical tape to prevent shorting (shorting can result in injury or fire)
• Do not expose battery to fire or intense heat as it may explode
6.2 Batter
y disposal:
This unit contains a maintenance-free, non-spillable, sealed lead-acid battery.
This battery is fully recyclable and should be accepted at any location that
accepts common automotive starter batteries. Examples of places that accept
these batteries are: County or municipal recycling drop-off centers, scrap metal
dealers and retailers who sell automotive replacement lead acid starter batteries.
For more information on recycling this battery, call toll-free (877) 288-7722.
7. SPECIFICATIONS
Model No . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . VEC012APM
Peak Ampere . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1200 Amps
Boost Ampere . . . . . . . . . . . . . . . . . 450 Instantaneous Cranking Amps
HEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12.75 in. (32.39 cm)
WIDTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 in (27.94 cm)
DEPTH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.5 in (13.97 cm)
WEIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 lbs. (7.26 Kg)
Battery Type 12Volt, 19AH/20HR Sealed, Rechargeable
Non-Spillable, Maintenance-free,
Jumper Cables . . . . . . . . . . . . . . . . . . . . . .Heavy Duty, Welding Cable
Cables Clamps . . . . . . . . . . . . . . . . . . . 450 Amp, Heavy Duty Clamps
Area Light . . . . . . . . . . . . . . . . . . . . . Three high Intensity White LEDs
Accessory Socket . . . . . . . . . . . . . . . . .Self-Resetting Breaker 20 Amps
DC Charging Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Volt DC
AC Charging Adapter . . .110/120 Volt AC (700mA, 12 Volt DC Output)
Reverse Polarity Detection . . . . . . . . . . . . . . . . . . . . . . .2.5 Volts (min)

Vector JUMP-START SYSTEM Specifications

Power

peak ampere	1200 Amps
boost ampere	450 Amps
instantaneous cranking amps	450 Amps

Battery

battery type	12Volt, 19AH/20HR Sealed, Rechargeable Non-Spillable, Maintenance-free
dc charging adapter	12 Volt DC
ac charging adapter	110/120 Volt AC (700mA, 12 Volt DC Output)

Cables and Clamps

jumper cables	Heavy Duty, Welding Cable
cables clamps	450 Amp, Heavy Duty Clamps
reverse polarity detection	2.5 Volts (min)

Weight and Dimensions

height	12.75 in (32.39 cm)
width	11 in (27.94 cm)
depth	5.5 in (13.97 cm)
weight	16 lbs (7.26 Kg)
