1612, 1624, 2424 and 2448 Series 5 Installation 15
© 2019 Vision Engraving Systems
2.3 Table Descriptions
16 Series Engraver Descriptions
(Refer to the diagrams on the following page)
1. Table Base Plate. This is the large flat plate upon which everything else is mounted.
All mechanical alignments are referenced to this plate, so the space upon which you place the engraving
table must be a reasonably level surface.
2. Y-Axis Linear Rails. Mounted on the table base plate are stainless steel rails with sealed bearings,
which allow the motion of the T-slot table in the Y-axis direction.
3. T-Slot Table. Also referred to as the work surface, this aluminum bed supported by the linear rails
allows placement of the engraving material or special clamps and fixtures. The slots in this table are
shaped with an upside-down T, with the bottom of the T being a single-line slot across the top of the
table. The slots are used to hold various accessory holders, clamps, and jigs. All t-slot accessories are
available on at www.visionengravers.com
4. Y-Axis Lead Screw. This is a threaded rod located underneath the T-slot table. Combined with the
stepper motor, the lead screw is rotated and causes the T-slot table to move along the rails in the Y-axis
direction. There is also a second lead screw called the X-axis lead screw. The X-axis lead screw is
contained within the gantry, and can be accessed by removing the black sheet metal gantry cover. The
X-axis lead screw is responsible for X-axis motion of the carriage assembly, moving it left and right
across the gantry.
5. Gantry Assembly. The gantry or “bridge” is a large, rectangular bar suspended across the width of the
table in the X-axis. The carriage assembly is supported and rides on the gantry in the X-axis.
6. Carriage Assembly. The carriage assembly houses the engraving spindle, Z-Axis mechanism and
engraving motor. The carriage moves along the gantry assembly on a set of sealed bearing. The carriage
assembly holds the engraving spindle; it raises and lowers the spindle during the engraving process
using a lead screw and stepper motor.
7. 25 Pin Connector. This connection port is used to connect the table to the system controller. The
connector is located near the rear of the table and on top of the base plate.
8. Y-Axis Stepper Motor. Drives the T-Slot table in the Y-Axis.
9. X-Axis Stepper Motor. Drives the carriage in the X-Axis. Located under the protective cover.
10. Edge Guides. Used as a back and side stop for locating material and clamps during set-up.
11. Engraving Motor. The engraving motor or “spindle motor”, is the large black motor on the top of the
carriage assembly. The engraving motor drives a belt and pulley system, which turns the engraving cutter
during the engraving process.
12. Spindle Cable. Connects to the system controller and provides power to the engraving motor.
