- Install brake depressor V.A.G 1869/2 between driver's
seat and brake pedal, and tension.
- Screw adapter VAS 5234/1 or adapter V.A.G 1869/1 onto
brake fluid reservoir.
- Connect filler hose of brake filling and bleeding tool VAS
5234 or brake filling and bleeding tool V.A.G 1869/ to
adapter.
Vehicles with manual transmission:
- Remove cover cap from bleeder screw of clutch slave
cylinder.
- Connect bleeder hose of collector bottle on bleeder screw
of clutch slave cylinder, open bleeder screw, and allow
approx. 0.1 liters to flow out. Close bleeder screw and
install cover cap onto it.
- Operate clutch pedal repeatedly.
Continuation for all vehicles:
- Remove cover caps from bleeder screws of wheel brake
cylinders and brake calipers.
- Connect bleeder hose of collector bottle to rear bleeder
screw
)
, open bleeder screw, and allow corresponding
bake fluid quantity to flow out (see table on page 01-5,
Table - Sequence / quantity of brake fluid: ). Close bleeder
screw.
)
For left-hand drive vehicles, bleed rear right first and for
right-hand drive vehicles bleed rear left first.
Repeat work procedure on other side of vehicle at rear.
- Connect bleeder hose of collector bottle to front bleeder
screw
)
, open bleeder screw, and allow corresponding
quantity to flow out (see table below). Close bleeder screw.
Repeat work procedure on other side of vehicle at front.
Table
-
Sequence / quantity of brake fluid:
Order:
brake calipers (Left Hand Drive -LHD-
vehicles)
Brake fluid quantity which must flow out of brake
calipers:
Right rear 0.4 to 0.5 liters
Left rear0.4 to 0.5 liters
Right front0.4 to 0.5 liters
