Technical Data
Operating manual VAS 5051B A01.4 08/04 All rights reserved.
2-5A5E00309941 //6.8.04//
VAS 5051B
2.3 Test Instruments
2.3.1 Multimeter
Caution
Maximum voltage of the U/R/D/I measuring lead: DC 50 V or 42 V
peak
Direct voltage at U/R/D/I
(Ri ≥ 1 MΩ)
Range Resolution Tolerance
-2 to +2 V 0.001 V ±0.5 % of m.
±2 mV
-20 to +20 V 0.01 V ±0.5 % of m.
±20 mV
-50 to +50 V 0.01 V ±0.5 % of m.
±50 mV
Alternating voltage
at U/R/D/I
(effective value,
50 Hz to 5 kHz,
crest factor max. 3,
Ri ≥ 1 MΩ)
Range Resolution Tolerance
0 to 2 V 0.001 V ±1.5 % of m.
±4 mV
0 to 20 V 0.01 V ±1.5 % of m.
±40 mV
0 to 40 V 0.01 V ±1.5 % of m.
±80 mV
Alternating voltage
at U/R/D/I
(effective value,
5 kHz to 10 kHz,
crest factor max. 3,
Ri ≥ 1 MΩ)
Range Resolution Tolerance
0 to 2 V 0.001 V ±5 % of m.
±4 mV
0 to 20 V 0.01 V ±5 % of m.
±40 mV
0 to 40 V
0.01 V ±5 % of m.
±80 mV
Direct current inline
(Ri ≤ 250 mΩ)
via U/R/D/I measuring lead
Range Resolution Tolerance
-0.2 to 0.2 A 0.0001 A ±1 % of m. ±1 mA
-2 to 2 A 0.001 A ±1 % of m. ±10 mA
Alternating Current inline
(effective value, 30 to
500 Hz, crest factor max. 3,
Ri ≤ 250 mΩ)
via U/R/D/I measuring lead
Range Resolution Tolerance
0 to 0.2 A 0.0001 A ±1.5 % of m. ±1 mA
0 to 2 A 0.001 A ±1.5 % of m. ±10 mA
