02 Instruments and controls
Right-hand stalk switch
02
68
* Option/accessory, for more information, see Introduction.
Rear window wiper and washer
0
G021418
Move the stalk switch forward to start rear win-
dow washing and wiping. The wiper blade
makes several extra sweeps once washing has
finished. The button at the end of the stalk
switch has three positions:
Intermittent wiping: Depress the top of the
button.
Neutral position: Function deactivated.
Constant speed: Depress the bottom of
the button.
Wiper – reversing
Engaging reverse gear while the windscreen
wipers are on initiates intermittent rear window
wiping. If the rear window wiper is already on
at normal speed, no change is made.
The function for intermittent wiping for reverse
can be deactivated. Volvo recommends that
you contact an authorised Volvo workshop.
Rain sensor*
G029053
The rain sensor automatically activates the
windscreen wipers based on how much water
it detects on the windscreen. The sensitivity of
the rain sensor can be adjusted using the
thumbwheel (C), see page 67.
Turn the thumbwheel upwards for higher sen-
sitivity and downwards for lower sensitivity, (an
extra sweep is made when the thumbwheel is
turned upwards).
On/Off
When activating the rain sensor, the remote
control key must be in position I or II and the
windscreen wiper stalk switch must be in posi-
tion 0 (not activated).
Activating the rain sensor:
– Press the button (B), see page 67. A display
symbol shows that the rain sensor is
active.
To turn the rain sensor off, either:
1. Press button (B)
2. Press the stalk switch downward to
another wiper program. If the stalk switch
is raised, the rain sensor will remain active,
the wipers make an extra sweep and then
return to rain sensor mode when the stalk
is released to position 0 (not activated), see
page 67.
The rain sensor is automatically deactivated
when the remote control key is removed from
the ignition switch or five minutes after the igni-
tion is switched off.
