REAR PANEL
23. USB 2.0 TERMINAL
Use the included USB 2.0 cable to connect with a computer. The
computer supplies power to the mixer and audio data can be sent
between the two. Alternatively, the terminal can be used as a USB
power socket (mains power or USB power bank) to supply the mixer
with power. Obviously, utilizing the terminal for this purpose, data
cannot be transferred or recorded. Using external power supply must
meet the following requirements:
Output voltage: 4.8V to 5.2V
Output current: 0.5A or more
BT CONNECTION
1. Activate the BT-function on your device (mobile phone, tablet etc.) from which you want to play the
music. See the operating instructions for that device.
2. Select “VMM” on your BT-device and make the BT-connection.
No password is required.
Attention: The BT distance is approx. 10 meter without any barrier.
