7 Appendix IV — Exploded View of System Saver 1200 Plus Series Air Dryer
45
Meritor WABCO Maintenance Manual 34 (Revised 03-16)
7 Appendix IV — Exploded View of System Saver 1200 Plus Series Air Dryer
Figure 7.1
Figure 7.1
4007692a
PRESSURE
RELIEF
VALVE
DESICCANT
CARTRIDGE
SYSTEM SAVER 1200 PLUS SERIES AIR DRYER
OUTLET
CHECK
VALVE
ASSEMBLY
GOVERNOR
O-RING
PURGE VALVE
ASSEMBLY
TURBO
CUT-OFF
VALVE
ASSEMBLY
HEATER
ASSEMBLY
