Technical Data
Combustion engine 13.4
45
[us] | 07/2021 | 5100060589 | BPS | Operator’s Manual
Type BPS1340Aws (Loxam)
Material number machine 5100060129
Underclearance [mm] 663
Operating weight [kg] 71
Nominal power** [kW] 2.6
Rated speed [1/min] 3600
Operating temperature range [°C] -15 - +45
Storage temperature range [°C] -15 - +40
Sound pressure level at operator station LpA [dB(A)] 95
Sound power level LWA, measured [dB(A* 104
Sound power level LWA guaranteed [dB(A)] 105
Vibration total value ahv [m/s2] 4.6
Measurement uncertainty of the total vibration value
ahv [m/s2]
0.5
*Depends on the soil conditions.
** Corresponds to the installed net power according to Directive 2000/14/EC.
13.4 Combustion engine
Engine manufacturer Honda
Material number engine 5100045994
Engine type GX 120
Combustion processes four-stroke
Cooling Air
Cylinder 1
Cubic capacity [cm3] 118
Inclined position max. [°] 20
Fuel type Gasoline
Fuel consumption [l/h] 1
Tank volume [l] 2,5
Oil specification SAE 10W-30
Oil filling max. [l] 0,6
Output max. [kW] 2,6
RPM [1/min] 3600
Standard SAE J1349
Exhaust-emission level EU Stage V, US Phase 3
CO2 emission* [g/kWh] 976
Spark plug type NGK BP-6 ES
Electrode gap [mm] 0,7 - 0,8
* Determined value of the CO2 emission during engine certification without consideration of the applications on
the machine.
13
