Technical Data PD 2A/3A
wc_td000085gb.fm 16
3.4 Dimensions
Item Revision
A
mm (in.)
B
mm (in.)
C
mm (in.)
X
mm (in.)
Y
mm (in.)
Z
mm (in.)
0007610
PDT2A
107- 635
(25)
1015
(40)
572
(22.5)
---
108+ 635
(25)
1015
(40)
610
(24)
---
0007611
PDT2A(I)
635
(25)
1015
(40)
572
(22.5)
---
