W 180 P

Preparing the Spray Material

The paints usually need to be diluted for use with the spray gun. You will nd guidelines

for sprayable dilutions in the following viscosity table (viscosity = consistency of the paint).

You can achieve the correct dilution by using the viscosity test cup.

Handling Table for Viscosity

Spray Material Viscosity: (Runout time in seconds)

Thinner-soluble varnishes/

primers 20-35 20-45

Water-soluble varnishes /

primers 20-50 20-60

Automobile spray paint 18-22 18-22

Wood preservatives,

disinfectants, plant protectants,

polishes, strippers, oils undiluted

Hammer eect enamel 25-35 30-45

Aluminium paints 20-30 20-30

Measuring the Viscosity

Dip the viscosity test cup (Illus. 1) completely into the spray material. Hold the test cup up

and measure the time (in seconds) until the liquid empties out. Compare the measured

"runout time" with the Viscosity Table.

Start-up

Before connecting to the mains supply, please be sure that the supply voltage is identical

with the value given on the rating plate (on the side of the spray gun).

1) Dilute the spray material according to the above table.

2) Place the container on a sheet of paper and ll it with the prepared spray material.

Attention! Do not operate the spray gun without spray material in the

container; this can lead to increased wear of the pump!

3) Position the spray gun on the container and turn the container to the right until the

container ts tightly (Illus. 2, arrow).

Activate the switch to start up the spray gun.

First the spray gun sucks in spray material, then after a few seconds the material emerges

from the nozzle. To accelerate the intake, turn the ne adjustment button to maximum.
