8 Technical characteristics
8.1 Mechanical characteristics
Dimensions 73 x 54.5 x 25.5 mm (excluding connectors)
Overall Dimension 88 x 54.5 x 25.5 mm
Weight
≈ 80 grams (modem only)
< 120 grams (modem + bridles + power supply cable)
Volume
101.5 cm
3
Housing
Aluminium profiled
The next page gives the dimensioning diagram of the modem including the
clearance areas to take into account for the installation of the modem.
