Replacement Parts List

Item Description Qty. Item Description Qty.

1 COVER/BASE, COUNTERWEIGHT SET 1 23 WASHER, LOCK, 5/16, ZP, HELICAL 1

2 NUT,LOCK,NY.IN,FULL,ZP,5/16-18 12 24 NUT, LOCK, NY .IN, FULL, ZP, 1/4-20 1

3 CASTER,PLATE,SWIV,3 D,250 CAP 2 25 ROD,PAWL RELEASE 1

4 BOLT,CARR,5/16-18X3/4,ZP 12 26 KNOB,BLK. 1”DIA,1/4-20 1

5 COVER,LIFT MECHANISM 1 27

TAPERED CANOPY PANEL,CARRIER ASSY or

RECTANGULAR CANOPY PANEL,CARRIER ASSY

6 SCREW,SM,PTH,#8 X 5/8,BLK.ZN 12 28 PIN, MAIN 2

7 SCREW,SELF DRILLNG,NO.10-16,.75 6 29 PIVOT BEARING,PANEL 6

8 HINGE, LOWER PANEL 1 MIDDLE PANEL,CARRIER ASSY 1

9 HANDLE,FOLD,PLASTIC,2.91 1 31 LEGACY CANOPY TOOL 1

10 CAPSCREW,GD2,ZP,1/4-20X1 1/4 1 32 PANEL ASSY,MIDDLE 1

11 HANDLE,CRANK 1 33 MAIN FRAME,PAINTED 1

12 COG,ALIGNMENT 2 34 BOLT, CARRIAGE, 3/8-16X2 1/4, ZP 6

13 PIVOT WLDMT, MID PANEL 1 35 NUT,LOCK,NY.IN,FULL,ZP,3/8-16 10

14 SCREW,SELF TAP, HWH, 1/4-20X3/4 4 36 PANEL ASSY,LOWER 1

15 ROD END, CANOPY, LOWER 1 37 CASTER,PLATE,SWIVEL,4D,250 CAP 2

16 CANOPY ROD 1 38 BOLT, CARRIAGE, 3/8-16X1, ZP 4

17 ROD END,CANOPY,UPPER 1 39 FRAME, LEFT HAND SIDE BASE 1

18 BRACKET, ROD END 1 40 FRAME, RIGHT HAND SIDE BASE 1

19 RECEIVER WLDMT 1 41 MAGNET, CERAMIC CUP 2

20 RATCHET WLDMT 1 42 SCREW, MACHINE, TH, #8-32X 3/4, ZP 2

21 RING, CATCHPLATE 2 43 O-RING, .449 OD X .171 ID 2

22 RIVET,BLIND,3/16,GRIP.251/.375 4 44 NUT, LOCK, NYLON INSERT, #8-32 2

45 CAP, SHAFT 1
