MAINTENANCE-SCRUB DECK - CYLINDRICAL
86037660 CHARIOT 11/09/06
4-13
4-13
1.
Hopper
2. Blade side squeegee
3. Side squeegee adjustment knob
4. Scrub brush motor
5. Scrub deck lift actuator
6. Side squeegee removal knob
7. Brush door
2
4
3
5
1
6
7
