17. Short Parts List
G.C.No. Part WHS Part No.
E01 064 BF Standard Terminal 225mm- 420mm 7 716 191 007
E01 065 BF Extended Terminal 420mm- 560mm 7 716 191 008
299 361 Digital Single Channel Programmer 7 716 192 003
299 360 Mechanical Single Channel Programmer 7 716 192 002
E01 053 Digistat CD (Radio Controlled Room Thermostat) 7 716 192 006
E00 748 BF Open Vent Kit 7 716 192 108
Pre-system Filling Loop 7 716 192 102
Mini Expansion Vessel 7 716 192 105
Acccessories For 24CDi BF
Key G.C. No. Part Manufacturer’s Reference Qty WHS
No. Part No.
26 378 312 Gas Valve Junkers Bosch, type CE 426 1 8 747 003 366 0
78 375 695 Burner – Natural Gas Aeromatic, ref. AC 23/05 3582 1 8 716 142 602 0
80 173 091 Burner Injector – Natural Gas Stereomatic, type 7, 4.5mm dia. 1 8 716 140 208 0
81 375 697 Spark Electrode Assembly Buccleuch, ref. BE/3462/SI 1 8 716 142 100 0
82 E01 612 Flame Sensor Buccleuch, ref. BE/3461/SI 1 8 716 120 345 0
95 299 515 Ignition Harness Buccleuch, ref. BE/3469/SI 1 8 716 120 229 0
61 299 352 Gas to Water Heat Exchanger Giannoni, ref. PR22 323 003, spec. D2107 1 8 716 142 800 0
68 E00 716 Automatic Air Vent Intermes, ref. 02.05.010 1 8 716 140 500 0
85 299 506 System Pressure Gauge Cewal, spec. D2111 1 8 716 142 300 0
40 375 699 Pressure Relief Valve Caleffi, ref. 312439 1 8 716 142 404 0
29 173 006 Circulating Pump Grundfoss, ref. 50 50 6601 1 8 716 143 100 0
25 173 001 Expansion Vessel Zilmet, ref. 301010 1 8 716 142 500 0
42 299 353 Water to Water Heat Exchanger Giannoni, ref. PVW 12 E, spec. D2108 1 8 716 142 900 0
34 173 005 Diverter Valve Giannoni, ref. V37/OM/I/F/4/A spec D2109 1 8 716 142 401 0
104 379 215 DHW Flow Restrictor Type E - White 1 8 716 141 054 0
105 378 416 Domestic Water Filter MPM, V3326 1 8 716 148 400 0
121 E01 309 Check Valve Assembly WHS 1 8 716 120 321 0
115 E01 307 Filling Valve Assembly WHS 1 8 716 120 319 0
84 173 014 Circuit Board – OF/BF Junkers Bosch, type Heatronic II KE 1 8 748 300 220 0
96 299 516 Transformer ERA, Ref. BV 066-0188.0 1 8 747 201 248 0
60 375 696 Thermister Sensor Elmwood, ref. 6655 - 9003 - 5 2 8 716 142 302 0
62 173 015 Overheat Thermostat Elmwood, ref. 2455 R - 98 - 789 1 8 716 142 303 0
133 299 354 Combustion Chamber Insulation Pack WHS 1 7 716 192 204 0
134 299 355 Fibre Washer Pack WHS 1 7 716 192 205 0
135 299 356 ‘O’ Ring Pack WHS 1 7 716 192 207 0
136 299 357 Fuse Pack WHS 1 7 716 192 206 0
