Worx WG163E.9 User Manual

2-in-1 Grass Trimmer/Edger
EN
14
ACCESSORIES
WG163E WG163E.1 WG163E.9
Flower guard 1 1 1
Charger
1
(WA3760)
1
(WA3760)
/
Battery pack
2
(WA3551.1)
1
(WA3551)
/
Spool (WA0004) 1 1 1
Safety guard 1 1 1
Edger wheel 1 1 1
We recommend that you purchase your accessories
from the same store that sold you the tool. Refer to
the accessory packaging for further details. Store
personnel can assist you and offer advice.
ASSEMBLY AND OPERATION
NOTE: Before using the tool, read the
instruction book carefully.
Intended Use
The machine is intended for the cutting of grass and
weeds under bushes, as well as on slopes and edges
that can not be reached with the lawn mower.
WARNING! The charger and battery pack are
specially designed to work together so do not
attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
WARNING! Always wear the eye protection.
Never lean over the trimmer head. Rocks or
debris can ricochet or be thrown into eyes and face
and cause blindness or other serious injury. When
operating unit, check for the following:
Wear eye protection and heavy clothing. Hold front
handle with one hand and auxiliary handle with
the other hand. Keep unit below waist level. Work
only from your right to your left to ensure debris is
thrown away from you. Without bending over, keep
line near and parallel to the ground (perpendicular
when edging) and not crowded into material being
cut.
WARNING! Make sure that line is fed out
before operation. Make sure motor is up
to full speed before trimming or edging.
WARNING! Only use 1.65mm diameter
cutting line. Other sizes of line will not feed
properly and will result in improper cutting head
function or can cause serious injury. Do not use other
material such as wire, string, rope, etc. Wire can
break off during cutting and become a dangerous
projectile that can cause serious injury.
ASSEMBLY & OPERATION
Action Figure
Assembly
Assembling the Safety Guard See Fig. A1, A2
Mounting the Edger Wheel
WARNING: Make Sure
the ON/OFF Switch
is Locked Off to Prevent
Accidental Starting.
See Fig. B
Installing and Removing the
Battery Pack
See Fig. C
Charging the battery pack
More details can be found in
charger’s manual
See Fig. D1
Checking the battery condition
(Only for WG163E.1 )
See Fig. D2
Operation
Safety ON/OFF Switch
WARNING! The cutting
head continues to rotate
after the trimmer has been
switched off; wait until it has
completely stopped then lay down
the tool.
See Fig. E
Trimming
- Adjusting the Shaft
WARNING! Make Sure the
ON/OFF Switch is Locked
Off to Prevent Accidental Starting.
See Fig. F
- Adjusting the Trimmer Head See Fig. G1, G2
- Adjusting the Auxiliary handle See Fig. H
- Trimming See Fig. I1
- Using the Flower Guard See Fig. I2
Edging
- Changing the tool into the
Edging mode
See Fig. J1, J2
- Edging See Fig. K
Command feeding the line See Fig. L
Manually feeding the line See Fig. M

Worx WG163E.9 Specifications

General

Type	String trimmer
Head type	Nylon line
Handle type	D-loop handle
Cutting width	300 mm
Line diameter	1.65 mm
Product color	Black, Metallic, Orange
Automatic line feed	Yes
Line length supplied	3 m
Cutting diameter (max)	- mm
Power source	Battery
Battery voltage	20 V

Weight and Dimensions

Weight	2000 g
