12
Cordless Lawn Trimmer
Lawn Edge Trimmer
WG168E
6.THREE SPEED SETTINGS (See Fig. F )
Your machine is fitted with a 3 Speed selector button
Speed 1 –Used for basic light trimming of short grass
Speed 2 –Used for medium / longer grass trimming –ie.
trimming against walls/fences etc.
Speed 3 –Used for tough over grown area’s of long
grass.
7. ADJUSTMENT OF AUXILIARY HANDLE (See
Fig. G)
Release the auxiliary handle locking clamp, move the the
auxiliary handle to the most comfortable and balanced
position. Close the clamp to tighten the handle.
NOTE: Make sure the handle is firmly secured in
place.
OPERATION
WARNING: Always wear the eye protection.
Never lean over the trimmer head. Rocks or debris
can ricochet or be thrown into eyes and face and cause
blindness or other serious injury. When operating unit,
check for the following:
Wear eye protection and heavy clothing. Hold front
handle with one hand and auxiliary handle with the
other hand. Keep unit below waist level. Work only from
your right to your left to ensure debris is thrown away
from you. Without bending over, keep line near and
parallel to the ground (perpendicular when edging) and
not crowded into material being cut.
WARNING: Make sure that line is fed out
before operation. Make sure motor is up to
full speed before trimming.
WARNING: Use only 2.0mm diameter
cutting line. Other sizes of line will not feed
properly and will result in improper cutting head
function or can cause serious injury. Do not use other
material such as wire, string, rope, etc. Wire can break
off during cutting and become a dangerous projectile
that can cause serious injury.
Trimming
Postion the trimmer head as shown in Fig. H1 for
trimming.
Keep the bottom of the trimmer head just above the
ground and at an angle. Allow only the tip of line to
make contact. Do not force trimmer line into work area.
7
8
D2
E
F
G
