Hedge Trimmer ENG
1. REAR HANDLE
2. SWITCH LEVER
3. FRONT HANDLE
4. FRONT SWITCH LEVER (All Around Switch Function)
5. EXTENSION BUTTON
6. FRONT HANDLE ROTATION BUTTON
7. LOCK NUT
8. SAFETY GUARD
9. BLADE (See Fig D)
10. BLADE COVER
TECHNICAL DATA
ACCESSORIES
1pc blade sheath
1pc blade guard
We recommend that you buy all your accessories from the store where you purchased the tool.
Use good quality accessories marked with a well-known brand name. Refer to the accessory
packaging for further details. Store personnel can also help and advise.
Model no. WG202 WG203
Rated Voltage 120V~60Hz
Rated Current 3.7 A 4.0 A
Cutting diameter 3/4”
Blade length 22” 24”
RatedNo-load speed 3200min
-1
Blade action Double action blades
Machine weight 9.2lbs 9.2lbs
