10
1. HANDLE
2. ON/OFF SWITCH
3. TUBE RELEASE BUTTON
4. BLOWER TUBE
5. BATTERY PACK
6. BATTERY PACK RELEASE BUTTONS (See Fig. D)
7. WALL MOUNT BRACKET* (See Fig. G1)
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
WG545 WG545.1
WG545.2
WG545.4 WG545.5 WG545.9 WG575 WG575.1 WG575.9
Voltage
20V Max* 32V Max**
No load speed
12500/min 13800/min
Blow speed
120mph
Charging time
5 hrs 2 hrs 45 min / 3-5 hrs /
Charger
WA3742 WA3868 WA3847 / WA3740 /
Machine weight
3.5 lbs 4.3 lbs 3.5 lbs 2.7 lbs 4.0 lbs 3.0 lbs
* Voltage measured without workload. Initial battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
** Voltage measured without workload. Initial battery voltage reaches maximum of 32 volts.
Nominal voltage is 28.8 volts.
