1. OPERATING BAIL
2. SAFETY BUTTON
3. HANDLE KNOB
4. FRONT CASTER WHEEL CONTROL BUTTON
5. FRONT CASTER WHEEL
6. FRONT CASTER WHEEL CUTTING HEIGHT ADJUSTMENT LEVER
7. MOTOR COVER
8. REAR WHEEL CUTTING HEIGHT ADJUSTMENT LEVER
9. REAR WHEEL
10. SAFETY FLAP
11. GRASS COLLECTION BAG
12. HANDLE BAR
13. SIDE-DISCHARGE COVER
14. SIDE-DISCHARGE CHUTE
15. MULCHING PLUG
16. BLADE BOLT (See Fig. L1)
17. BLADE (See Fig. L1)
18. SPACER (See Fig. L1)
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
Rated voltage 120V~60Hz
Rated power 13A
Deck diameter 20˝
Cutting diameter 19˝
Front wheel diameter 7˝
Rear wheel diameter 10˝
Cutting height 1-1/4-4˝
Cutting height positions 7
Grass collection capacity 1.4 bushels(50L)
Machine weight 48.5 lbs
