Test chart: i1iO supports optimized testcharts for high-speed scanning
measurement and standard testcharts for patch-mode measurement
Media length: 230 mm (9”)
Media width: 320 mm (12.6”)
Media thickness: max. 10 mm (0.39”)
Minimal patch size:
:
i1Pro 3 PLUS - 16 x 16 mm (0.63” x 0.63”)
i1Pro 3 - 6 x 8 mm (0.24” x 0.31”)
Interface and
Power Supply:
USB Socket Power Socket
Mains supply: Auto-Ranging Power Supply: 100-240 V AC, 50/60 Hz; 1.0 A
Input i1iO: 24 V DC, 1500 mA
Data Interface: USB 1.1
Dimensions: Physical dimensions: 510 x 460 x 170 mm (20” x 18.1” x 6.7)
Weight: 4.5 kg (9.9 Ib) (excluding i1Pro)
Specication Technische Daten Spécications Specica Especicación
1: +24 DC
2: GND
3: Not connected
Case: GND
1
2
3
仕様 技术规格

X-Rite i1iO Specifications

General

Brand	X-Rite
Model	i1iO
Category	Scanner
Language	English
