X10 SUPERREMOTE UR47A User Manual

1716
You can change 1-4/5-8 slide switch to
allow you to control X10 Modules set to
9-12/13-16:
C HANGING THE X10 S LIDE
SWITCH
SETTING :
1. Press and hold
SETUP until the LED
indicator lights
steadily. Release
Setup button.
2. Press and hold ALL
OFF (LED blinks off)
for about 8 seconds
until the LED
indicator turns off.
The above procedure changes the switch
on the side of the remote to control X10
Modules set to 9-12 or 13-16. To
change it back to 1-4/5-8, repeat the
above procedure, pressing LIGHTS ON
instead of ALL OFF.
CONTROLLING
X10 MODULES
If you have purchased and installed a
Transceiver Module, you can control it
and other X10 modules as follows:
The 4 rocker keys at the bottom of the
remote control X10 Modules set to 1, 2,
3, and 4, from left to right. Press the top
of the rocker key to turn the Module ON.
Press the bottom of the rocker to turn the
Module OFF. Press and hold the top
rocker to brighten, and the bottom rocker
to dim lights connected to Lamp Modules
and Wall Switch Modules (does not dim
or brighten Appliance Modules, but turns
them on if they were off).
Use the slide switch on the side of the
remote to select control of X10 Modules
set to 1-4 or 5-8.
The Lights On button turns on ALL lights
connected to Lamp Modules and Wall
Switch Modules (set to the same
Housecode as the remote). This button
does not affect Appliance Modules.
The All Off button turns off ALL X10
Modules set to the same Housecode as
the remote, including Appliance
Modules.
These 4 rocker keys give instant control
of 4 X-10 Modules set to Unit Codes 1-4
or 5-8 no matter what mode you are in
(TV, VCR, etc.)
