Page 16 Model PA435X
© 2003 Xantech Corporation
SPECIFICATIONS
Number of channels 4
Power Output
Rated continuous power, each channel, all six channels
simultaneously driven, 20 Hz to 20kHz, at rated THD
35 Watts at 8 Ohms
Power Output
Short term continuous, each channel, 2 channels driven,
1 kHz, at rated THD
55 Watts at 8 Ohms
80 Watts at 4 Ohms
Bridged Power Output
Short term continuous, one pair driven at 1 kHz, at rated THD
150 Watts at 8 Ohms
Rated THD < 0.08%
Damping Factor
at 50 Hz, half rated power
> 100
S/N Ratio
A-weighted, shorted inputs, ref to rated power
> 100 dB
Frequency Response
at 1 Watt, ± 3dB
12 Hz to 55 kHz
Input Sensitivity
at rated power, stereo mode, input gain
Max: 0.2 V
Default: 1.0 V
Minimum: 3V
Input Impedance Local Inputs: 22 kOhms
Common Audio Buss Inputs: 70kOhms
Power Source 120 VAC, 60 Hz
TMRA 35° Celsius (95° F). If this temperature is exceeded,
you will need to provide additional ventilation to ensure proper
operation.
240 VAC, 50 Hz (European version)
Power Consumption No signal: 14 Watts
4 Channels at 1/10 rated power: 105 Watts
4 Channels at rated power: 420 Watts
4 Channels Bridged at 465 Watts
Remote On/Off/Mute CI1 & CI2 Voltage/Current +5 V to +30 VDC (16 mA at +12 VDC)
Line Fuse Rating 120V version: 6.25A Slow Blow 250 VAC
240V version: 3.15A Time-Lag 250 VAC
Dimensions 17” W x 4” H x 11.5” D
(432 mm W x 102 mm H x 293 mm D)
Weight 20.4 lbs (9.3 Kg)
