Setting up Xerox
®
DocuMate
®
Scanners and Xerox
®
FreeFlow MakeReady
®
Page 3
vii) Select each scanner in turn to verify the installation was
successful by scanning a test page.
Do not select a scanner source with ‘WIA’ in the listed name.
Results will be less than desirable due to a limited feature set,
and are untested in this environment.
viii) During the test phase, when the ‘Scan’ button has been clicked,
the Driver UI will be displayed. First, set driver to ‘Advanced’
(Dropdown 1), and then navigate to the following tabs (shown below)
for your installed scanner(s).
ix) Locate the ‘Color Correction’ drop-down. There are two choices
available:
“Monitor” uses Gamma tables optimized for LCD display and should
be used for image archiving.
“Printer” uses Gamma tables optimized for reproduction and
recommended for use with FreeFlow MakeReady in a production
print environment.
x) Select the Color Correction best suited to your work environment,
and click ‘Save’.
Note:
If using flatbed and ADF scanners, it is advisable to
set the Color Correction the same for both.
xi) Once testing has been concluded, and your scanners are working
as expected, you can either combine the scanners as shown in the
next section, or move directly to the last section.
3. Combining Scanner Drivers
i) This can only be achieved after completing section ‘2. Driver
Installation’. If you are not using a flatbed scanner, or wish to keep
the scanners drivers separate then this section can be skipped.
ii) Depending on your Operating System, navigate to the
corresponding hardware device page in the Windows Control Panel.
For Windows XP and Windows Vista
Navigate to
“Scanners and Cameras”
window
Right-click on the flatbed
scanner, and select
‘Properties’
For Windows 8 and Windows 7
Navigate to “Devices and
Printers” window
Right-click on the flatbed
scanner, and select ‘Scan
Properties’
To Next Page
