Xerox Phaser 6700 Service Manual

Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-101
Routine Maintenance and Service Items
Description
Part Number
Fuser 110V
Fuser 220V
126K32220
126K32230
Black Imaging Unit
Cyan Imaging Unit
Magenta Imaging Unit
Yellow Imaging Unit
108R00974
108R00971
108R00972
108R00973
Standard Capacity Black Toner Cartridge for NA/XE
Standard Capacity Cyan Toner Cartridge for NA/XE
Standard Capacity Magenta Toner Cartridge for NA/XE
Standard Capacity Yellow Toner Cartridge for NA/XE
106R01506
106R01503
106R01504
106R01505
High Capacity Black Toner Cartridge for NA/XE
High Capacity Cyan Toner Cartridge for NA/XE
High Capacity Magenta Toner Cartridge for NA/XE
High Capacity Yellow Toner Cartridge for NA/XE
106R01510
106R01507
106R01508
106R01509
Standard Capacity Black Toner Cartridge for DMO
Standard Capacity Cyan Toner Cartridge for DMO
Standard Capacity Magenta Toner Cartridge for DMO
Standard Capacity Yellow Toner Cartridge for DMO
106R01514
106R01511
106R01512
106R01513
High Capacity Black Toner Cartridge for DMO
High Capacity Cyan Toner Cartridge for DMO
High Capacity Magenta Toner Cartridge for DMO
High Capacity Yellow Toner Cartridge for DMO
106R01526
106R01523
106R01524
106R01525
Metered Black Toner Cartridge
Metered Cyan Toner Cartridge
Metered Magenta Toner Cartridge
Metered Yellow Toner Cartridge
106R01522
106R01519
106R01520
106R01521
Waste Toner Cartridge 108R00975
Maintenance Kit (Transfer Belt and Transfer Roller) 604K73140
Staple Cartridge (3 cartridges of 5K staples) 008R12941
Power Cords
Description Part Number
Power Cord, North America (NEMA 5-15), 125 V, 15A 117E29520
Power Cord, Cable Assy, EUR, 240 V 152S06413
Power Cord, Cable Assy, UK, 240 V 152S06414
Power Cord, Denmark, 230V 152S06415
Power Cord, Australia, 230V 117E29490
Power Cord, China, 220V 117E35030
Power Cord, Argentina, 220V 117E35040
Power Cord, Switzerland, 230V 152S06416
www MK-Electronic de

Xerox Phaser 6700 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum duty cycle	120000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Internal memory	1024 MB
Maximum internal memory	2048 MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	59 dB
Total input capacity	550 sheets
Total output capacity	500 sheets
Multi-Purpose tray input capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4
Multi-purpose tray media types	Letterhead
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Current rating	12 A
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	118 W
Power consumption (printing)	672 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CE, FCC Part 15, Class A, GOST, UL
Product color	White
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Authentication method	HTTPS, IP filtering, IPPS, IPSec, IPv6, SMTP, SNMPv3, SSLv3

Weight and Dimensions

Dimensions (WxDxH)	560 x 516 x 429 mm
