Page #21 background imageLoading...
Page #21 background image
Xerox® Security Guide for Office Class Products: AltaLink® VersaLink®
November 2018 Page 19
o Prevent impersonation (aka spoofing) of a printer/MFP
o Automatically prevent connection of non-approved print products
o Smart rules-based policies to govern user interaction with network printing products
Provide simplified implementation of security policies for printers and MFPs by:
o Providing real time policy violation alerts and logging
o Enforcing network segmentation policy
o Isolating the printing products to prevent general access to printers and MFPs in
restricted areas
Automated access to policy enforcement
Provide extensive reporting of printing product network activity
AltaLink® Multifunction
VersaLink®
Multifunction
VersaLink® Printers
B8045, B8055, B8065, B8075,
B8090, C8030, C8035, C8045,
C8055, C8070
B405, B605, B615, B7025,
B7030, B7035, C405, C505,
C605, C7020, C7025, C7030
B400, B600, B610, C400, C500,
C600, C7000, C8000, C9000
Network Access Control
Cisco ISE
Supported
Supported
Supported
Contextual Endpoint Connection Management
Traditionally network connection management has been limited to managing endpoints by IP address and
use of VLANs and firewalls. This is effective, but highly complex to manage for every endpoint on a
network. Managing, maintaining, and reviewing the ACLs (and the necessary change management and
audit processes to support them) quickly become prohibitively expensive. It also lacks the ability to
manage endpoints contextually.
Connectivity of AltaLink® and VersaLink® devices can be fully managed contextually by Cisco
TrustSec. TrustSec uses Security Group Tags (SGT) that are associated with an endpoint’s user, device,
and location attributes. SG-ACLs can also block unwanted traffic so that malicious reconnaissance
activities and even remote exploitation from malware can be effectively prevented.
FIPS140-2 Compliance Validation
When enabled, the product will validate its current configuration to identify cryptographic modules in use.
Modules which are not FIPS 140-2 (Level 1) compliant will be reported.
AltaLink® products include FIPS compliant algorithms of SNMPv3 and Kerberos, however an exception
can be approved to run these in non-FIPS compliant mode when configured for non-FIPS algorithms.
VersaLink® products use encryption algorithms for Kerberos, SMB, SNMPv3, and PDF Direct Print
Service that are not approved by FIPS140-2. They can however operate in FIPS140-2 approved Mode in
order to maintain compatibility with conventional products after an exception is approved by a system
administrator. They do not use FIPS compliant algorithms when in this configuration.
Additional Network Security Controls
Additional network security controls are discussed in the following sections.
Endpoint Firewall Options
AltaLink® Multifunction
VersaLink®
Multifunction
VersaLink® Printers
B8045, B8055, B8065, B8075,
B8090, C8030, C8035, C8045,
C8055, C8070
B405, B605, B615, B7025,
B7030, B7035, C405, C505,
C605, C7020, C7025, C7030
B400, B600, B610, C400, C500,
C600, C7000, C8000, C9000
Firewall
Stateful Packet Filter
IP Whitelisting
IP Whitelisting

Table of Contents

Other manuals for Xerox VersaLink C500

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox VersaLink C500 and is the answer not in the manual?

Xerox VersaLink C500 Specifications

General IconGeneral
ColorYes
N-up printing2, 4, 6, 8, 9, 16
Print technologyLaser
Maximum resolution1200 x 2400 DPI
Duplex printing modeAuto
Warm-up time (from sleep mode)11 s
Time to first page (black, normal)5 s
Time to first page (color, normal)5.3 s
Print margins (top, bottom, right, left)4 mm
Print speed (black, normal quality, A4/US Letter)43 ppm
Duplex print speed (black, normal quality, A4/US Letter)42 ppm
DisplayLCD
Control typeTouch
CertificationCE
Product colorBlack, Blue, White
Display diagonal5 \
Market positioningBusiness
Cables includedAC
Processor cores2
Noise level (idle)33.6 dB
Sound power level (standby)4.9 dB
Sound power level (printing)7.17 dB
Sound pressure level (printing)56.2 dB
Standard interfacesEthernet, USB 3.2 Gen 1 (3.1 Gen 1)
Optional connectivityWireless LAN
Sustainability certificatesENERGY STAR
Wi-FiNo
Cabling technology10/100/1000Base-T(X)
Security algorithms256-bit AES, FIPS 140-2, SNMPv3, SSL/TLS
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Mopria Print Service, Xerox PrintBack
Supported network protocols (IPv4)TCP/IP: HTTP/HTTPS, Internet Printing Protocol, LPR/LPD, Raw Socket Printing/Port 9100, IPv4/IPv6, WSD
PCL fonts83
Printer fontsPCL, PostScript
Printing colorsBlack, Cyan, Magenta, Yellow
Country of originVietnam
Maximum duty cycle120000 pages per month
Recommended duty cycle0 - 10000 pages per month
Number of PostScript fonts136
Number of print cartridges4
Page description languagesPostScript 3
Average cartridge yield (CMY)2400 pages
Average cartridge yield (black)5000 pages
Maximum cartridge yield (black)40000 pages
Current rating8 A
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)74 W
Power consumption (printing)730 W
Power consumption (PowerSave)0.9 W
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra
Linux operating systems supportedFedora 25, RedHat EL Linux, openSUSE 13.2
Other operating systems supportedHP-UX 11.31, IBM iSeries, Solaris 11
Server operating systems supportedWindows 2000 Server, Windows Server 2003, Windows Server 2008, Windows Server 2008 R2, Windows Server 2012
Windows operating systems supportedWindows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Paper input typePaper tray
Total input capacity700 sheets
Total output capacity500 sheets
Maximum input capacity3250 sheets
Paper tray 1 input capacity550 sheets
Total number of input trays1
Multi-Purpose tray input capacity150 sheets
Storage temperature (T-T)0 - 35 °C
Operating temperature (T-T)10 - 32 °C
Operating relative humidity (H-H)10 - 85 %
Custom media width76 - 216 mm
Maximum print size216 x 356 mm
Custom media length127 - 356 mm
Paper tray media typesBond paper, Card stock, Envelopes, Labels, Letterhead, Lightweight paper, Plain paper, Pre-Printed, Recycled paper
Paper tray media weight60 - 220 g/m²
Non-ISO print media sizesLegal
Multi-purpose tray media typesBond paper, Envelopes, Labels, Letterhead, Plain paper, Preprinted forms, Recycled paper
Maximum ISO A-series paper sizeA4
Paper tray media weight (imperial)16 - 80 lbs
Harmonized System (HS) code84433210
Weight and Dimensions IconWeight and Dimensions
Depth465.5 mm
Width427.4 mm
Height443.4 mm
Package weightWeight of the packaged product in gram.
