Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-28
Item Parts Name Part Number
1. COVER ASSY TOP (WITH 3, 14, 15, 98) 848K 89792
2. TRAY EXTENSION CBV 050E 26771
3. COVER ASSY SUB TOP (with 14) REF Only
4. COVER ASSY REAR 604K 93730
5. BEARING BTR L 013E 38091
6. BEARING BTR R 013E 38101
7. ROLL ASSY BTR 022K 78520
8. KIT COVER REAR INNER LQ (WITH LABEL) 604K 92630
9. SWITCH I/L ASSY (with 10) 676K 12440
10. HOLDER IL REAR --
11. COVER WINDOW TNR 822E 10711
12. HINGE CVR SFP 803E 21931
13. COVER SIDE L 822E 10672
14. COVER TOP REAR --
15. COVER OPP --
16. COVER FRONT TOP SFP 822E10631
17. COVER ASSY FRONT (WITH 18-21) 848K 89812
18. COVER FRONT SIDE SFP 822E 10770
19. COVER JAM CL PE 822E 10650
20. BRACKET COVER JAM 869E 09731
21. COVER FRONT SFP --
98. PWB ASSY LED 101K 68040
