Parts List
Phaser 6020/6022 and WorkCentre 6025/6027 MFP
Service Manual
5-75
Item Part Name Part Number
1. COVER TOP AIO (WITH 2, 3, 15) --
2. COVER EXTENSION AIO --
3. COVER TOP AIO 822E 12945
4. COVER ASSY REAR AIO 604K 93750
5. BEARING BRT L 013E 38091
6. BEARING BTR R 013E 38101
7. ROLL ASSY BTR 022K 78520
8. COVER ASSY INNER REAR (with 43) AIO-4inLQ 6027 604K 92650
9. SWITCH I/L ASSY (WITH 10) 676K 12440
10. HOLDER IL REAR --
11. COVER WINDOW TNR AIO LQ 822E 11203
12. HINGE CVR AIO 803E 21980
13. COVER FRONT LOWER AIO VB --
14. COVER ASSY SIDE L AIO (with 19) 848K 90573
15. TRAY EXIT AIO --
16. COVER FRONT UPPER AIO --
17. COVER SIDE R AIO --
18. KIT COVER FRONT AIO (WITH 13,16,17,21,22) 604K 93781
19. COVER SIDE L UPPER AIO 822E 12961
20. COVER SIDE R UPPER AIO 822E 12971
21. COVER JAM CL PE --
22. BRACKET COVER JAM --
23. COVER SIDE REAR 822E11221
24. FILM ASSY EXIT --
98. KIT COVER EXTENSION ASSY AIO (WITH 2,15) 604K 92660
