How to Install
The Xiaomi Smart Camera C400 can be placed on flat surfaces, such
as desks, dining tables, and co ee tables. It can also be mounted on a
wall.
Mounting the Camera on a Wall ：
1. First use a pencil to mark the positions for the base mounting holes
on the wall, then drill two holes at the marked positions. The
diameter of each hole is approximately 6 mm, and the depth is
approximately 30 mm.
2. Insert the plastic wall plugs into the drilled holes.
3. Place the side of the base with arrows facing forward, and then
align the holes. Insert the screws and then tighten them into the wall
plugs with a Phillips head screwdriver.
on the base, and then turn it clockwise until it locks into place.
2
