Xilinx KCU105 Software Install And Board Setup

Optional Hardware Setup
Hook up the SMA cables as shown
IBERT Test:
– J29 to J31 (White)
– J28 to J30 (Black)
Clocking Test
– J33 to J34 (Red)
– J32 to J35 (Yellow)
User SMA Loopback
– J36 to J37 (Green)
Note: Presentation applies to the KCU105
