Xilinx ML505 Quick Start

ML505 BSB Hardware
• The ML505 MicroBlaze design
hardware includes:
– DDR2 Interface (256 MB)
– BRAM
– External Memory Controller (EMC)
• ZBT SRAM
– Networking
– UART
– Interrupt Controller
– System ACE CF Interface
– GPIO (IIC, LEDs and LCD)
– PLB Arbiter
Note: Presentation applies to the ML505 and ML506

Xilinx ML505 Specifications

General

Brand	Xilinx
Model	ML505
Category	Motherboard
Language	English
