Xprinter XP-460 Series User Manual

3.4 Loading Label for Peel-off Mode (Option)
1. Open the peel-off module by pulling it out.
Peel-off Roller
Peel-off Panel
2. Thread the label, printing side facing up, through the label guides and place it on top
of the platen.
3. Thread the label through the liner opening, which is beneath the roller.
4. Adjust the center-biased label guides by finger to fit the edge of the label backing.
Adjustment
Roller
Peel-off panel
5. Push the peel-off panel back to the printer.
6. Close the top cover.
12
