Yaesu FT-1807M - Exploded View & Miscellaneous Parts

3
Exploded View & Miscellaneous Parts
g
c
d
e
f
g
g
d
d
d
c
c
c
f
f
f
f
f
f
f
f
e
e
e
e
e
e
e
e
e
e
M4090178
SPEAKER
Non-designated parts are available only as
part of a designated assembly.
S8002063
CAP-SP
RA0753600
FRONT PANEL
RA0753800
RUBBER KNOB
G6090169
LCD
RA0754500
INTER CONNECTOR
RA0754600
DIFFUSER
CNTL UNIT
MAIN UNIT
RA0754400
GROUND PLATE
RA0753400
CHASSIS
RA0754200
ENCODER KNOB
RA0754100
KNOB (VOL/CQL)
RA0754300
REFLECTOR
P1091172
CONNECTOR
G1094344
RA55H4047M
T9206876 (FT-1807M)
T9206955 (FT-1807E)
WIRE ASSY
CP8579001
CASE ASSY
w/SP NET: S8002087
DESCRIPTION
MICROPHONE
(
MH-48A6J
)
DC CABLE
(
FT-1807M
)
DC CABLE
(
FT-1807E
)
SPARE FUSE
(
15 A: FT-1807M
)
SPARE FUSE
(
15 A: FT-1807E
)
BRACKET
(
MMB-36
)
SCREW SET
VXSTD P/N
AAA43X001
T9021715
T9022815
Q0000081
Q0000075
D6000055
CB0297000
ACCESSORIES
REF.
c
d
e
f
g
QTY.
4
4
11
9
3
DESCRIPTION
SEMS SCREW ASM3X10NI
TAPTITE SCREW M2X12NI
TAPTITE SCREW M3X8NI
TAPTITE SCREW M2.6X6B
HEXA SOCKET BOLT M3X20B
VXSTD P/N
U03310002
U24112002
U24308002
U36206007
U51320007
T9207248
WIRE ASSY
S8002118 (2 pcs)
CUSHION
T9206438A
WIRE ASSY
