PCB with Components ---------

C 2701 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A A1

C 2702 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B3

C 2703 CHIP CAP. 75pF 50V CH GRM1882C1H750JZ01D K22174232 1- A A1

C 2704 CHIP TA.CAP. 10uF 16V TEESVA1C106M8R K78120077 1- A B3

C 2705 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C4

C 2706 CHIP CAP. 0.001uF 25V CH GRM1882C1E102JA01D K22144204 1- A B1

C 2707 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A A1

C 2709 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3

C 2710 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A A2

C 2711 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 1- A A1

C 2712 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 1- A B2

C 2713 CHIP CAP. 470pF 50V CH GRM1882C1H471JA01D K22174249 1- A B3

C 2714 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 1- A A1

C 2715 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B1

C 2716 AL.ELECTRO.CAP. 100uF 10V RVZ-10V101MF55U-R2 K48100008 1- A B3

C 2717 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A B4

C 2718 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 1- A B2

C 2719 CHIP CAP. 0.1uF 25V B GRM188B11E104KA01D K22144814 1- A B2

C 2720 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A B3

C 2721 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A B2

C 2722 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A B2

C 2723 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A3

C 2724 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 2725 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A A3

C 2726 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A3

C 2727 CHIP TA.CAP. 1uF 35V TEESVA1V105M8R K78160032 1- A B1

C 2728 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B1

C 2729 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A3

C 2730 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A1

C 2731 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A B1

C 2732 CHIP CAP. 0.001uF 50V CH GRM1882C1H102JA01D K22174275 1- A A3

C 2733 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A A1

C 2734 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A1

C 2736 CHIP CAP. 33pF 50V CH GRM1882C1H330JA01D K22174223 1- A C1

C 2738 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A1

C 2739 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C1

C 2740 CHIP CAP. 2pF 50V CK GRM1884C1H2R0BA01D K22174272 1- A A1

C 2741 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A A1

C 2743 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C1

C 2744 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A A2

C 2745 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C1

C 2746 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C3

C 2747 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C1

C 2748 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A2

C 2749 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A B1

C 2751 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C1

C 2752 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A2

C 2753 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C1

C 2754 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B2

C 2756 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C2

C 2757 CHIP CAP. 39pF 50V CH GRM1882C1H390JA01D K22174225 1- A A2

C 2758 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2

C 2759 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A A2

C 2760 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B1

C 2761 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C1

C 2762 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C2

C 2763 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2

C 2764 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2

C 2765 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C1

C 2767 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A B2

C 2769 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A D2

C 2770 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B3

C 2771 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A A2

C 2772 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2

C 2773 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C3

C 2774 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A2

C 2775 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C3

C 2777 CHIP CAP. 22pF 50V CH GRM1882C1H220JA01D K22174219 1- A B2

C 2778 CHIP CAP. 0.047uF 25V B GRM188B11E473KA01D K22144811 1- A A2

C 2779 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A C3

CF2701 CERAMIC FILTER LTM455HW-AD H3900588 1- A C2

CF2702 CERAMIC FILTER CFJ455K8 H3900553 1- A D2
