Specifications
Packing List (Check Before Installing Rotator)
Available Options
GA-2500 Shock Absorber Plate
GS-680U Universal Bearing
GS-050 Thrust Bearing (50 mm mast)
GS-065 Thrust Bearing (65 mm mast)
GC-038B Mast Clamp
C-25MWP Control Cable (25 m)
C-40MWP Control Cable (40 m)
GL-33 Mast Adjustment Plate
G-450A G-650A
Rotation Torque 600 kgf-cm (43 ft-lbs.)
Braking Torque 3000 kgf-cm (217 ft-lbs.) 5000 kgf-cm (362 ft-lbs.)
Maximum Vertical load Continuous load 100 kg or less (Instantaneous load 300 kg)
Mast Outside Diameter f32 to f63 (center protrudes by f48 to f52)
Rotation Range 450°
360° Rotation Time 63 seconds at 50 Hz, 51 seconds at 60 Hz
Braking Type Mechanical stopper Mechanical and electrical stoppers
Antenna K Coefficient 100 180
Wind Loading Area (Pole type) 0.5 m
2
´ 0.5 m
(Tower type) 1 m
2
2 m
2
Maximum Continuous Duty 3 minutes
Operating Temperature Range 0 ~ 40 °C: Controller -20 ~ 40 °C: Rotor
Rotor Dimensions and Weight f186
´ 263, approx. 3.5 kg
Controller Dimensions and Weight
190 (W)
´ 125 (H)
´ 150(D), approx. 2.7 kg
Power Supply Voltage AC 100 ~ 120 V, 50 ~ 60 Hz
Power Supply Current Consumption
0.5 A
Rotor 1
Controller 1
U bolts 2
M8´16 Bolts 4
Hex. Nuts 4
Spring Washers 8
Flat Washers 4
7-pin Round Plug 1 set
6-pin Rectanglar Plug 1 set
Rubber Boot 1
User Manual 1
