E
2-15
EMD40410
Warning indicator
8 Fuel warning
If the fuel level decreases to one segment
the fuel level warning segment 1 begins
blinking.
8 Low battery voltage warning
If battery voltage drops, the display 2 will
be automatically turned on and it begins
blinking.
cC
Do not continue to operate the engine if a
warning device has activated. Refer to
the TROUBLESHOOTING section in this
manual. Consult a Yamaha dealer if the
problem cannot be located and corrected.
802031
TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
YAMAHA
set
mode
q
w
802026
TRIP TIME BATT
SPEED
qw
EMD40310
Fuel meter
The fuel level is displayed by eight seg-
ments. When all segments are showing,
the fuel is full.
cC
The Yamaha fuel tank sensor is different
from a conventional-type sensor. A
wrong setting of the selector switch on
the meter will give incorrect readings.
Consult Yamaha dealer for correct set-
ting.
NOTE:
The fuel reading can be affected by the
position of the sensor in the fuel tank and
the attitude of the boat in the water. Oper-
ation with bow-up trim or continuous
turning can give false readings.
802032TRIP TIME BATT
Km/h
knot
mph
km
mile
SPEED
64C-9-18-2 2/18/03 9:59 AM Page 16
