Setting Up
MG16/4, MG12/4
26
■ Mounting the MG16/4
(1) Two metal rack-mount supports are screwed onto the unit. Use
a screwdriver to remove these supports.
(2) Turn the supports over, and fasten them into place again using
the same screws.
(3) Mount the unit into the rack, and fasten it into place.
If you wish you may move the left support to the
right side and the right support to the left side, as
shown in the drawing.
Do not install the mixer near power amps or other
heat-generating devices.
■ Mounting the MG12/4
(1) Two metal rack-mount supports are screwed onto the unit. Use
a screwdriver to remove these supports.
(2) Turn the supports over, and fasten them into place again using
the same screws.
(3) Mount the unit into the rack, and fasten it into place.
Do not install the mixer near power amps or other
heat-generating devices.
Rack Mounting
NOTE
