DIGITAL ELECTRONIC CONTROL WIRE HARNESS
MAIN WIRE HARNESS
Between engine and remote control unit
DUAL STATION EXT WIRE HARNESS 1
Between main RC and 2nd RC
DUAL STATION EXT WIRE HARNESS 2
Between main RC and 2nd RC
Part No. Length (L) Remarks
6X6-8258A-10 7 m, 23 ft
For F350/F300/F250
[Digital Electronic Control]
6X6-8258A-20 8 m, 26 ft
6X6-8258A-30 10 m, 32 ft
6X6-8258A-40 12 m, 38 ft
Part No. Length (L) Remarks
6X6-8258A-A0 5 m, 16 ft
For F350/F300/F250
[Digital Electronic Control]
6X6-8258A-C0 8 m, 26 ft
Part No. Length (L) Remarks
6X6-8258A-B0 5 m, 16 ft
For F350/F300/F250
[Digital Electronic Control]
6X6-8258A-D0 8 m, 26 ft
(L)
BR
L
B
R
W
W
B
W
R
W
Y
RB
Br
L
R
B
W
BR
L
B
R
W
W
B
W
R
W
Y
RB
Br
L
R
B
W
B R B
RBW
B R B
RBW
LW
LW
LW
LW
Br
X
Y Br
X
Y
(L)
R
Or
R
Y
Or
R R R
R
Y
2nd RC Main RC
(L)
