IDENTIFICATION OF COMPONENTS
FRONT PANEL
* ( ) indicates the page number on which the control part is best described.
* Control functions other than shown below are the same with
the corresponding ones on the remote control transmitter.
* The PLAY/PAUSE button on the main unit has both the
functions of the PLAY button and the PAUSE button on the
remote control transmitter.
* The SKIP/SEARCH button on the main unit has both the
functions of the SKIP buttons and the SEARCH buttons on
the remote control transmitter.
CDC-655
CDC-501
POWER
I2345
SKIP/SEARCH
PLAYXCHANGE OPEN/CLOSE
PLAY/
PAUSE
STOP
DISC
NATURAL SOUND COMPACT DISC PLAYER
CDC-901
POWER switch (p. 8)
PLAYXCHANGE button (p. 9)
PHONES jack (p. 12)
Remote control sensor (p. 22)
Display panel
PEAK button (p. 21)
OUTPUT LEVEL control (p. 12)
(“UP” is identical with “+” and
“DOWN” with “–” of the
OUTPUT LEVEL buttons on the
remote control transmitter.)
POWER switch (p. 8)
Disc tray (p. 8)
Disc tray (p. 8)
DISC-select buttons (p. 8)
PLAYXCHANGE button (p. 9)
Display panel
Remote control sensor (p. 22)
DISC-select buttons (p. 8)
