IDENTIFICATION OF COMPONENTS
FRONT PANEL
* ( ) indicates the page number on which the control and its function are best described.
* The control functions on the main unit and on the remote
control transmitter are virtually identical, with the exceptions
below.
* The (PLAY/PAUSE) button on the main unit has both
the functions of the PLAY button and the PAUSE button on
the remote control transmitter.
* The SKIP/SEARCH buttons on the main unit have both the
functions of the SKIP button and the SEARCH button on the
remote control transmitter.
POWER switch (p. 8) PHONES jack (p. 12)
Play/Pause button (p. 8, 9)DISC-select buttons (p. 8)
Remote control sensor (p. 22)
Display panel
PEAK button (p. 21)
SKIP/SEARCH
buttons (p. 10)
POWER switch (p. 8)
Disc tray (p. 8)
Disc tray (p. 8)
PLAYXCHANGE button (p. 9)
Play/Pause button (p. 8, 9)
Display panel DISC-select buttons (p. 8) SKIP/SEARCH buttons (p. 10)Remote control sensor (p. 22)
PLAYXCHANGE button (p. 9)
CDC-505
CDC-905
